Kenwood KAC-M3004
General FeaturesRMS POWER Output 4Ω: 50W x 4
RMS POWER Output 2Ω: 75W x 4
RMS POWER Output Bridged: 150W x 2
Dimensions(WxHxD): 165mm x 45mm x 99mm
Singal Sensing Turn-on
Conformal Coating *1
*1: Do not install the unit in a spot exposed to direct sunlight or excessive heat or humidity. Also avoid places with too much dust or the possibility of water splashing.
Title Compact 4 Channel Digital Amplifier
Amplifier Type Class D
Maximum Power Output 600W
Specifications Signal to Noise Ratio 89dB (Reference: Rated Power into 4Ohms at 14.4V)
Frequency Response 20Hz-20kHz (+0dB, -1dB)
Input Impedance 10k ohm
Speaker Impedance 4Ω (2Ω to 8Ω allowable)
Bridged connection 4Ω to 8Ω allowable
Audio Section Low-Pass Filter Built in Variable Low-Pass Filter (50Hz-200Hz, -12dB/oct)
High-Pass Filter Built in Variable Low-Pass Filter (50Hz-200Hz, -12dB/oct)
Filter Selector 1 LPF-OFF-HPF
RCA Input Sensitivity 0.2 V - 5.0 V
Speaker Level Input Sensitivity 4.0 V - 12.0 V
Terminals Battery & Ground Screw Type Terminal Block (Ni) (M4)
Speaker Output MOLEX Connector with AWG16 200mm Wire
Line In RCA (Ni)
General Dimensions(WxHxD) 165mm x 45mm x 99mm
Weight(kg) 0.76kg
Operating Voltage 14.4V(11-16V allowable)
Current Consumption 22 A
Key Features
CEA-2006 Compliant
Class D
2 Ohms Load Capability
Speaker Level Input
Signal Sensing Turn-on
Power MOS-FET Switching Power Supply
Extruded Aluminum Heat Sink Design
